Cable Ladder Type

We Can Give You the Assurance To Load Design Capacity of Your Cable Ladder System.

There are not many manufacturer that can provide Loading Simulation on the Load Design Capacity of the Cable Ladder. Not Only we can provide you with the Loading Simulation, we can provide Physical and Real Loading Test on the Cable Ladder to determine its capacity to meet the Loading Design.

Simulating the Load on Cable Ladder can give you the additional assurance that the design of the cable support is safe to take the load required.

Actual Loading Test on Cable Ladder System can be done on Actual Specimen of the Type of Cable Support being Purchased.

Note: This added value facilities is only provided to give you the assurance of the Load Design for the Cable Ladder, it is by no means should be taken as replacement of proper design engineer and proper installation methods. Please consult Your Own professional Engineer for Endorsement or Design Load Requirement on the different installation application. We shall not be liable for any information used in this site which we believe to be as accurate as it can be. The results you are getting is not typical results as it may varies depending on many factors.

Download our Cable Ladder System Catalog Here.


Cable Ladder Type.

Cable Ladder Products are part of the Cable Management System Product Family. Cable Ladder is also called Cable Ladder Tray and at times is confused with Perforated Tray Type.

Using Cable Ladder is one of the most cost efficient and safe way to manage your Cabling needs. The rigidity of the profiles makes it suitable for big power cables and heavy duty usage, of course this will require proper loading and profile design of the Cable Ladder that is going to be used.

Cable Ladder Systems are commonly used in different sector of Industries as an effective way to manage cabling needs of the industries from High Rise Building, Marine, Oil & Gas, Power Generations, Utilities, Infrastructures, and even the smaller industries or factories.

The Common International Standard used for Cable Ladder is NEMA VE-1 / CSA C22.2 No 129.1-09 and IEC 61537 for Metal Cable Tray System.


Cable Ladder Used in Petro Chemical Projects



Cable Ladder  Used in Steel Mill Projects



Cable Ladder Used in Wholesale Building


Cable-Ladder Telecom

Download our Cable Ladder System Catalogue Here.


Cable Ladder Type

Cable Ladder Type can be classified under 3 Classification:

1. Profiles.

Type U – SLU Type W – SLW Type Extrude.
Light Duty
Light Duty
1. I-Type
Cable Ladder Type U SLWE - Light Duty Economical Type Ladder Type I
Heavy Duty
Heavy Duty
2. E-Type
Cable Ladder Type U SLW - Heavy Duty Sigma - Extruded Profile

*Customized Profiles can be produced upon request depending on the size of the requirements.

Customised Profile Solutions:

SLC - Customized SLW - Customized


2. Materials.

Commonly Used Material and the standard thickness for our Cable Ladders are as follows:

Material Thickness (mm)
Hot Rolled Steel – SPHC JIS3131G 1.6, 1.8, 2.0, 2.5
Cold Rolled Steel – SPCC 0.8, 1.0
Galvanized Steel – SGHC, SGH400 1.0, 1.6, 1.8, 2.0, 2.5
High Corrosion Resistance Galv Steel – ZAM, POSMAC 1.6, 2.0, 2.5
Aluminium Profile 6063 2.0, 3.0
Aluminium AA1100, 5052 1.5, 2.0, 3.0
Stainless Steel SS304, SS316 1.5, 2.0, 2.5

*For Other Special Material Request can be produced upon request depending on the size of the requirements.

3. Coatings.

Epoxy Powder Coating can be done on Cable Ladder System instead of Hot Dip Galvanized. For Coating Colour, it can be customized depending on request and Quantity involved.

For Coating Colour Code, Standard Code used internationally is the RAL Code that can be seen on the RAL colour Chart found Here.

Download our Cable Tray / Management System  Catalog Here.

Customized Solutions is available for different Material Types and Specification, Please Contact Us for any customization solutions Here.

Installation Guidelines.

Cable Ladder Installation Guidelines is provided under NEMA Standard Nema VE2, which can be downloaded for FREE Here.

* Our Cable Ladder Support System is being Type Tested by 3rd Party Inspection Bodies – Llyod's Register



The Difference Types of Cable Management system.


Cable Ladder Tray Trunking


Local Content Certification for Indonesia Market

SPHC – Hot Rolled Steel
SPHC Cable Ladder SPHC-B
 Aluminium Cable Ladder
Aluminium Cable Ladder F Aluminium-B
Stainless Steel 304 & 316
Stainless Steel Cable Ladder Front Stainless Steel-B
